Applications
Label Rolls for Retail and Logistics
As handheld and mobile printers become more popular, demand for small-core label rolls is growing rapidly.
Supermarket Price Labels
Self-adhesive price and shelf labels for supermarkets and retail chains.
Logistics & Shipping Labels
Thermal labels for warehouses, courier services and local delivery.
Handheld & Bluetooth Printer Rolls
Small-core label rolls sized for portable and Bluetooth label printers.
Lines & Specifications
Compare GPPE Label Roll Lines
Small core
Fully Automatic Small Core Label Roll Converting Line
For 0.5–1 inch small-core label rolls: die-cutting, waste collection, slitter rewinder, core loading, tail label closure, grouping and shrink packaging in one line.
View product.webp)
Turret rewinding
Fully Automatic Turret Label Converting
Turret slitter rewinder with automatic core loading, non-stop rewinding with printing, die-cutting and pile waste collection.
View product| Parameter | Small Core Label Roll Line | Turret Label Converting |
|---|---|---|
| Web width | 330 / 450 / 550 mm | 330 / 450 / 550 mm |
| Paper weight | 40–100 gsm | 40–150 gsm |
| Slitting width | Min. 30 mm | Min. 30 mm |
| Finished roll OD | 30–150 mm | 25–350 mm |
| Core ID | 12–25.4 mm (0.5–1 inch) | 25–76 mm (1 / 1.5 / 3 inch shafts) |
| Die-cut length | 12–26 inch | 9–19 inch |
| Production | 13 s/cycle (10 m rolls) | 130 cycles/h (45 m rolls) |
| Packaging speed | Max. 15 packs/min | Max. 30 packs/min |
| Rewinding speed | Max. 300 m/min | Max. 120 m/min |
| Cutting length accuracy | ±1 mm | ±1 mm, cut at label gap |
Also see the Blue Tooth Printer Label Roll Production Line. Specifications are from GPPE standard configurations.
Models & Configuration
Models on Sale and How to Choose
Fully automatic slitting and converting equipment for thermal self-adhesive label rolls.
| Model | Automation | Operators | Mother roll | Material | Efficiency |
|---|---|---|---|---|---|
| GP-L330 | Fully automatic | No dedicated operator | W330 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L450 | Fully automatic | No dedicated operator | W450 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L550 | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L330-1C | Fully automatic | No dedicated operator | W330 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L450-1C | Fully automatic | No dedicated operator | W450 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L550-2C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L550-3C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-L550-4C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA330 | Fully automatic | No dedicated operator | W330 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA450 | Fully automatic | No dedicated operator | W450 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA550 | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA450-2C | Fully automatic | No dedicated operator | W450 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA450-3C | Fully automatic | No dedicated operator | W450 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA550-2C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA550-3C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
| GP-LA550-4C | Fully automatic | No dedicated operator | W550 mm, OD 1270 mm | Face 40–70 gsm, liner 40–80 gsm | 25 s/cycle (40 m) |
Standard functions
- Unwinding
- Die-cutting
- Slitting
- Rewinding
- Cutting
- Hot-melt glue roll start
- Label tail closure
- Automatic core conveying
Optional functions
- Printing
- Drying
- Turning
- Web guiding
- Accumulator
- Servo tension control
- Glueless roll start
- Roll separation and end flattening
- Roll pushing and counting
- Conveying
- Packaging
- Carton erecting and packing
- Palletizing
- Customers
- Self-adhesive roll converting plants
- Applications
- Slitting and converting of cash register and label rolls for supermarkets, logistics, warehousing and local delivery
How to choose your line
Answer these questions in your inquiry and our engineers will recommend a model and configuration.
- Which machine width do you prefer: 330 mm, 450 mm or 550 mm? For the 330 model, the efficiency is 15 s/cycle (25 m rolls).
- Do you need a packaging line? Packaging style: POF transparent or black PE?
- Do you need inline carton packing and palletizing?
- Do you need flexo printing? 1 color, 2 colors or more (max. 6 colors inline)?
- Die-cutting unit: single or double die-cut?
- Roll end closing: glue or glueless?
- Do you need an end mark unit?
- Which core range do you produce: 0.5–2 inch or 1–3 inch?
More Label Formats
Fan-Fold and Linerless Label Lines
Two more fully automatic line families for self-adhesive converters.
Fan-Fold Label Lines
Printing, slitting and packaging lines for fan-fold products such as logistics labels and boarding passes.
Models
- GP-RL330-FD
- GP-RL450-FD
- GP-RL550-FD
Linerless Label Lines
Fully automatic printing, converting, slitting and packaging lines for linerless self-adhesive products.
Models
- GP-LN550
- GP-LN1100
- GP-LN550-WP
- GP-LN1100-WP
Label Quality
Every Label Kept Perfect
- Cutting at the label gapCutting accuracy of ±1 mm keeps each label intact.
- Label tail closureThe roll tail is closed with a label, not tape.
- Special glue designThe label end peels easily from the core without leaving glue on the label.
- Pile waste collectionNo need to stop the line to change waste rolls.
- Quick-change air shafts1, 1.5 and 3 inch quick-disassembling shafts; the machine adjusts automatically when shafts are changed.
FAQ
Common Questions About Label Roll Lines
Can GPPE build a turret label line wider than 550 mm?
Yes, as a custom build. Standard GPPE turret label lines are 330, 450 and 550 mm wide; a 560 mm (22 inch) web, for example, is built to order. The turret line runs 1000 mm OD mother rolls and finished rolls down to 41 mm wide, with a web guide and a splicing table as standard.
Can roll-end labels be printed inline by thermal transfer?
Yes, as a custom option. GPPE label lines close each roll tail with a label instead of tape, and inline thermal-transfer printing of these roll-end labels can be built into the turret line on request.
How many printing colors can a turret label line have?
Turret label lines, including the 330 mm model, can be built with 1 to 6 flexo printing colors; the customer chooses the number of colors.
Request a Quote
Plan Your Label Roll Line
Send us the details below and our engineers will recommend a line configuration for your products and output.
- Label type and application
- Face material, liner and gsm
- Jumbo roll width and outer diameter
- Label size, gap and die-cut shape
- Core size (0.5 / 1 / 1.5 / 3 inch) and finished roll OD
- Labels or meters per roll
- Target daily output and packaging method
- Destination country and power supply
